Tech Specifications

Wireless
Wireless
Connector
  • Duplex LC Connector
Single/bi Direction
  • Single-direction
Wavelength
  • 850nm
Output Optical Power (TX Optical Power)
  • MAX.: -3dBm
  • MIN.: -8 dBm
Input Optical Power (RX Optical Power)
  • MAX.: – 3 dBm
  • MIN.: – 22 dBm
Sensitivity
  •  -22dBm
Cable Type
  • Multi-mode 50/125um or 62.5/125um fibre
General
EMI
  • CE, FCC, VCCI
Safety
  • LVD, EN60825-1, EN 60825-2
Features
  • Hot Pluggable
  • MSA Compliant
  • RoHS Compliant
Compliant Standard
  • IEEE802.3z
  • 1000BASE-SX
Transceiver Type
  • SFP
Fiber Channel FC-PI standard
  • 100-M6-SN-I/100-M5-SN-I
Fiber Media support
  • Multi-Mode
Distance
  • 62.5/125um: 300m
  • 50/125um: 550m
Speed
  • 1.25Gbps
Power
  •  3.3V
Max Input Current
  • 300mA
Power Budget (MIN Power Budget)
  • 14d B
MAX Power Budget
  • 19d B
Heat Generated
  • 1.782kJ/h
MTBF (hours)
  • 224,167 hours
Physical
Operation Temperature
  • -40~85℃
Storage Temperature
  • -40~85℃
Humidity (Operating)
  • 5%~95%
Humidity (Storage)
  • 5%~95%
Dimension ( W x D x H )
  • 13.7 x 55.4 x 8.5mm
Weight(g)
  • 20g
Bail latch colour
  • Black
